CBF Materials – Composite Basalt Fiber

15 times stiffer & stronger than normal plastic.

  • Strength-to-weight ratio is more than 2 times higher than for 2024-T351 Aluminum.
  • 5 times lighter than steel and strong as stainless steel.
  • A 750m spool will be enough to fabricate a fully composite 55х55х55 mm cube or a fully composite A4-sized plate with a thickness of 2.5mm.
  • The volume ratio of carbon or basalt fiber in the final product is about 25%.

Anisoprint technology provides a wide range of applications in aerospace, automotive, healthcare, manufacturing, sport, transport – every area where strength and lightweight are required.

Related documents

Specifications

Desity g/cm³

1.7

Tesile modulus in fiber direction, Gpa

22

Poisson ratio 21

0.34

Tensil ultimate stress in fiber direction, Mpa

600

Tensil elongation in fiber direction, %

2.8

Compressive modulus in fiber direction, Gpa

20

Compressive ultimate stress in fiber direction, Mpa

195

Compressive elongation in fiber direction, %

1.2

Flexural Strength, Mpa

-
